Full Grating is a type of press-fit grating, unlike Press-Locked Grating, where the bearing bar and crossbar have the same cross section, cut in the middle. The Bearing Bar is a bar that rests on supports at both ends and has no slots on the lower edge.
Technical Parameters
1. Material: Carbon steel, stainless steel, or aluminum
2.Surface treatment: Hot-dip galvanizing, electro-galvanizing or spraying treatment can be selected , and anodizing treatment can be provided for aluminum materials.
3.Bear Bar Type: Flat type, Tooth type.
4. Size: We provide grids with hole spacing types not limited to those in the table, but please note that to prevent deformation, please consult our designers for specific sizes and grid hole spacing, and they will answer your questions.
| Full Grating load-bearing rod 2~3mm common grid spacing | |||||
| Bearing rod mm | Crossbar mm | ||||
| 22.2 | 16.65 | 22.2 | - | 44.4 | 66.6 |
| 33.3 | 16.65 | 22.2 | 33.3 | 66.6 | |
| 44.4 | 16.65 | 22.2 | 44.4 | - | |
| 66.6 | 16.65 | 22.2 | 33.3 | - | 66.6 |
| Full Grating load-bearing rod 5mm common grid spacing | ||||
| Bearing rod mm | Crossbar mm | |||
| 33.3 | 16.65 | 33.3 | 66.6 | 99.9 |
| 66.6 | 16.65 | 33.3 | 66.6 | - |
| 99.9 | 16.65 | 33.3 | - | 99.9 |
| Standard bearing bar profiles | |||||||||||||||||||
| Bearing Bar 2mm | 20/2 | 25/2 | 30/2 | 35/2 | 40/2 | 45/2 | 50/2 | ||||||||||||
| Bearing Bar 3mm | 20/3 | 25/3 | 30/3 | 35/3 | 40/3 | 45/3 | 50/3 | 60/3 | 70/3 | 80/3 | 90/3 | 100/3 | |||||||
| Bearing Bar 4mm | - | 25/4 | 35/4 | 40/4 | 45/4 | 50/4 | 60/4 | 70/4 | 80/4 | 90/4 | 100/4 | ||||||||
| Bearing Bar 5mm | - | 25/5 | 30/5 | 35/5 | 40/5 | 45/5 | 50/5 | 60/5 | 70/5 | 80/5 | 90/5 | 100/5 | 110/5 | 120/5 | 130/5 | 140/5 | 150/5 | 160/5 | 170/5 |
Features
Full Grating is its unique and beautiful design, but its load-bearing capacity is much lower than that of press-locked or press-welded gratings. The load-bearing rod is cut from the middle, so this type of grating requires thicker load-bearing rods than other gratings to withstand a certain load.
Customized Service
We understand that every project is unique, so we offer a comprehensive custom service to our customers . Our experienced engineers and designers will work closely with you to ensure the product meets your exact specifications.
1. Size and Shape: We can produce steel grating in any size and shape you require.
2. Load Capacity: Customize load capacity to match your specific application.
3. Surface Treatment: Choose from hot-dip galvanizing, painting or other special surface treatments.
4. Special Designs: We can create custom designs for complex applications or unique project requirements.
Application Fields
Full Grating can be used as ventilation grilles or railing fillers, and is widely used in civil and commercial buildings, theaters, subways, urban railways and other public engineering fields. It can be used for ceilings, indoor and outdoor decoration, platform aisles, ventilation windows (wells), advertising plaques, various covers, etc.
