Sidewalk Steel Grating, also known as Ride Way Steel Grating and Light Duty Steel Grating, is a high-performance, versatile building material designed for sidewalks, walkways, platforms and other occasions that need to withstand pedestrian and light vehicle loads . It is made of high-quality steel and is carefully designed and processed to provide a safe and stable walking surface. They are available in a variety of sizes and configurations to meet the specific needs of different projects.
Technical Parameters
1. Material : Sidewalk Steel Grating mainly uses high-quality carbon steel or stainless steel. Carbon steel has good strength and toughness, while stainless steel has excellent corrosion resistance.
2. Specifications and dimensions : Common mesh sizes of Sidewalk Steel Grating are 30mm×100mm, 40mm×100mm, etc., which can be customized according to actual load-bearing and drainage requirements. Common specifications of Bearing Bar are: 20mmX3mm, 30mmX3mm, 32mmX5mm, etc.
3. Load-bearing capacity : Depending on the model, it can withstand a weight of 2 to 5 tons per square meter. Sidewalk Steel Grating can fully meet the passage needs of pedestrians and small vehicles.
4. Surface treatment : After hot-dip galvanizing, the zinc layer thickness can reach 40-100μm , which greatly improves the corrosion resistance and has a service life of more than 20 years . A variety of color customization can meet the aesthetic requirements of different projects .
5. Anti-slip performance : In wet and slippery environments, the surface of Sidewalk Steel Grating usually adopts anti-slip designs, such as teeth and patterns, to increase friction and prevent pedestrians from slipping.
Customized Service
Our design team can provide you with a full range of customized services. Whether you need a special size, shape, load capacity, or personalized surface treatment, our professional team can tailor it for you. Just provide detailed design requirements and specification parameters, and we will ensure that the final product perfectly fits your project needs.
Application Fields
1. Urban sidewalks : widely used in urban streets, park trails, commercial areas, etc., providing pedestrians with a safe and comfortable walking surface.
2. Bridge sidewalks : In bridge construction, steel gratings can be used as sidewalk slabs. Due to their light weight and high strength, they can effectively reduce the weight of the bridge while ensuring structural safety.
3. Public facilities : Sidewalk steel grilles can be seen on the sidewalks of transportation hubs such as subway stations, train stations, airports, as well as in squares, parking lots and other places.
4. Commercial Center : Pedestrian walkways in commercial centers and shopping districts need to withstand more traffic and wear and tear, and the durability of steel gratings is fully demonstrated in these places.
Product Advantages
High Strength and Durability
High-quality steel and advanced manufacturing technology give the steel grating excellent strength and durability, able to withstand long-term use and the test of harsh environments.
Good drainage performance
The unique grid design allows rainwater to drain quickly to avoid water accumulation, ensuring pedestrian safety while reducing the risks of slippery roads.
Beautiful and modern
The simple and elegant appearance can be integrated with various urban landscapes and architectural styles to enhance the beauty of the overall environment.
Easy to install and maintain
Lightweight and modular design, easy to install and disassemble, reducing construction costs and time. Post-maintenance is also very simple, just need to clean regularly.
